    Black HF Rack Mounted UPS Battery Backup 40KVA 220V 50Hz / 110V 60Hz

    Ask Lasest Price
    Brand Name : LIRUISI
    Model Number : HY 40KVA
    Price : negotiation
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 9999 units
    Delivery Time : 8 working days
    • Product Details
    • Company Profile

    Black HF Rack Mounted UPS Battery Backup 40KVA 220V 50Hz / 110V 60Hz

    LIRUISI HF Machine Tower UPS Uninterruptible Power Supply HY 40KVA

    Product introduction:

    HY40KVA is equipped with dual DSP controllers, rectification, inverter, charging, discharge all realize DSP digital control, power module independent current sharing control, no single point of failure risk, is a collection of today's power electronics cutting-edge technology in one UPS high-end power products.


    way of working:

    Three in three out, double conversion online work three in three out operation.


    The characteristics of tower-type uninterruptible power supply (UPS) are as follows:
    High reliability: Due to the double conversion technology used in tower-type UPS, it has high stability and reliability, ensuring continuous power supply.
    High energy efficiency: In design, tower-type UPS focuses on energy efficiency through intelligent control technology to optimize energy utilization and reduce energy consumption.


    Three in three out high frequency tower UPS system
    Product modelThree-phase electrical input, three-phase electrical output
    HY40KVA
    Specifications30KW
    Technical parameters
    input voltage380V/400V/415V
    Input methodsingle in single out/three in single out/three in three out
    power factor>0.99
    current distortion rate<3%
    Voltage range25%~-25%, full load / 25%~-40%, linear derating between 100% and 70% load capacity
    Frequency range40-70HZ
    voltage accuracy± 0.5% (balanced load)
    Dynamic voltage transient2% (0~ 100% load change
    voltage distortion rate<0.5% (linear load) / THD<3% (nonlinear load)
    peak ratio3:01:00
    overload capacity105% long-term work / 110%, 1h / 125%, 10min / 150%, 1min / >150%, immediate shutdown
    System efficiencyNormal mode: 95%, Economic mode: 9
    Battery Mode Efficiency95%
    Battery configuration12V, X32 (±16~±20 knots optional)
    Size DxWxH438×500×130 mm
